CShells.Nuplane 0.0.30

CShells.Nuplane

CShells.Nuplane is an optional adapter that lets CShells discover features from assemblies Nuplane has already loaded for active packages. Add it only to hosts that compose Nuplane package loading and CShells.

Compose after Nuplane loading

Configure Nuplane autoload and any existing package observers first. Then explicitly select the adapter from the CShells builder:

using CShells.DependencyInjection;
using CShells.Nuplane;
using Microsoft.Extensions.DependencyInjection;
using Nuplane;
using Nuplane.Loading.Hosting.Builder;

IServiceCollection services = new ServiceCollection();
services.AddNuplane(nuplane =>
{
    nuplane.AutoloadPackages();
    // Add existing Nuplane observers here.
});

var shells = services.AddCShells();
shells.WithNuplaneFeatureDiscovery();

AddNuplane accepts a configuration callback and returns IServiceCollection. Calling WithNuplaneFeatureDiscovery afterward appends the CShells adapter observer after Nuplane's autoloader and existing observer registrations. The adapter uses one root coordinator for both Nuplane observation and CShells build participation. Do not register another coordinator through OnPackagesChanged<T>().

The provider queries IPackageAssemblyCatalog and contributes each PackageAssemblies.Assemblies collection in package order. These are already-loaded Assembly instances. The adapter does not read AssemblyReferences, load packages, or activate them. Adding the package alone does not replace CShells' current feature sources; the host opts in by calling WithNuplaneFeatureDiscovery.

Choose refresh and reload behavior

Generic defaults keep observer work enabled, refresh on changes or retained freshness, and leave automatic reload off:

shells.WithNuplaneFeatureDiscovery(options =>
{
    options.Enabled = true;
    options.RefreshTrigger = NuplaneRefreshTrigger.ChangedOrPending;
    options.AutoReload = false;
});

Configure host profiles independently. Foundation.Host can refresh and reload on every delivered eligible completion:

shells.WithNuplaneFeatureDiscovery(options =>
{
    options.RefreshTrigger = NuplaneRefreshTrigger.EveryEligibleCompletion;
    options.AutoReload = true;
});

Workbench can refresh only for changes or pending freshness and leave active shells alone:

shells.WithNuplaneFeatureDiscovery(options =>
{
    options.RefreshTrigger = NuplaneRefreshTrigger.ChangedOrPending;
    options.AutoReload = false;
});

An eligible completion is a delivered OnPackagesReconciledAsync callback with at least one successfully applied package or a committed removal. ChangedOrPending scans after additions, updates, removals, or a previous failed/deferred refresh. An unchanged completion with a fresh catalog and no pending reload does no work. EveryEligibleCompletion scans each eligible delivery, including unchanged successful applications.

Enabled = false suppresses new observer-driven refresh and reload requests. It does not disable the assembly provider's normal query when CShells initializes the feature catalog, and it does not discard freshness already pending for a later build. Reloading is independent: with AutoReload = false, a refresh updates catalog metadata while active shells keep their current generation. Disabling automatic reload pauses an already-pending failed reload; while disabled, new work does not create a reload request. A later eligible delivery with automatic reload enabled may retry retained failed reload work.

The adapter reads the current options once for each eligible reconciliation delivery and copies the four policy values before recording work. Standard IOptionsMonitor configuration therefore applies on the next eligible delivery, including values bound from a reloaded IConfiguration; changes do not start a background refresh or reload by themselves. The current delivery keeps the policy it captured even if configuration changes while its refresh is running. Build participation does not read options. Use Configure, Bind, or dependency-aware AddOptions configuration so the registered monitor owns the live values. A custom IOptionsMonitor<NuplaneIntegrationOptions> registration is supported; replacing only IOptions<NuplaneIntegrationOptions> is unsupported.

Diagnose observer operation failures

When logging is registered, an ordinary nonfatal failure from admitted reconciliation work produces one adapter Error record with the original exception, the PackageChangeSet.CorrelationId, and the OnPackagesReconciledAsync operation name. The adapter then rethrows the same exception so Nuplane retains its observer warning and continuation behavior. Requested-token cancellation, the documented fatal exceptions, build-time refresh failures, and returned per-shell ReloadResult.Error values remain outside this diagnostic boundary. With no logging provider, the adapter uses NullLogger and preserves the same failure propagation.

As with the framework's other logging consumers, exception-preserving diagnostics assume registered logging providers do not throw from ILogger.Log; logger-provider failures are outside this adapter contract.

Refresh cold shells before construction

When a package completion arrives with no active shell, the adapter records catalog freshness and returns without scanning assemblies, activating a shell, or reloading. The next requested shell build consumes pending freshness before CShells initializes or reads the feature catalog. A successful refresh is committed even if later shell initialization fails, so the next build can reuse that fresh snapshot.

Refresh requests and acknowledgements use separate epochs. A failed or cancelled refresh remains pending. A source change arriving during refresh remains outstanding after the in-flight refresh commits its captured epoch. The build participant returns a no-op lease and does not provide assembly-readability, load-context, or generation-lifetime protection.

Report host-specific reload failures

IShellRegistry.ReloadActiveAsync returns one ReloadResult per active shell. The callback receives a stable read-only copy of those original results, including partial errors and nested exception chains. Use standard options configuration when reporting needs another service:

using CShells.Nuplane;
using Microsoft.Extensions.Logging;

services.AddOptions<NuplaneIntegrationOptions>()
    .Configure<ILoggerFactory>((options, loggerFactory) =>
    {
        var logger = loggerFactory.CreateLogger("ShellReloadResults");
        options.OnReloadResults = (results, _) =>
        {
            foreach (var result in results.Where(result => result.Error is not null))
                logger.LogError(result.Error, "Reloading shell {Shell} failed.", result.Name);
            return ValueTask.CompletedTask;
        };
    });

The coordinator evaluates every ReloadResult.Error independently of the callback. Partial errors, thrown or cancelled registry calls, and callback failures retain reload work for a later eligible completion. A callback can report or translate host-specific refusals without replacing exception objects. A failure after one or more shells have already promoted does not roll those promotions back. The callback may request a manual shell build or reload because the refresh gate is released before automatic reload results are delivered; reentrant Nuplane observer dispatch is not part of this contract.

Package retirement and unload remain owned by the host/runtime layer that manages Nuplane packages.
