ReactiveUI.SourceGenerators 5.0.0

ReactiveUI.SourceGenerators

ReactiveUI.SourceGenerators writes ReactiveUI boilerplate for you when you build: reactive properties, commands, IReactiveObject implementations, IViewFor<T> views, derived lists, reactive collections and WinForms control hosts. The generated code uses no reflection, so it works with trimming and Native AOT.

The same repository also builds ReactiveUI.Binding, which generates the code behind WhenAnyValue, Bind, BindCommand, ToProperty and [ObservableAsProperty]. The two packages work together and share their infrastructure.

• Minimum requirements
  • C# 12.0
  • Visual Studio 17.8 (Roslyn 4.8) or the .NET 8 SDK; partial properties need Visual Studio 17.14 or later
  • ReactiveUI 23.2.28 or later

Table of contents

• Installation
• Overview
• Roslyn and Visual Studio support
• Migration from ReactiveUI.Fody
• Reactive properties
• Reactive commands
• Views
• Derived lists and collections
• WinForms control hosts
• Working with ReactiveUI.Binding
• Credits

Installation

dotnet add package ReactiveUI.SourceGenerators

Load the package with PrivateAssets="all" so the generator does not flow to projects that reference yours:

<PackageReference Include="ReactiveUI.SourceGenerators" Version="..." PrivateAssets="all" />

The attributes ([Reactive], [ReactiveCommand] and the rest) are public types in the package's ReactiveUI.SourceGenerators assembly. The generators do not declare them in your project, so assemblies that share internals through InternalsVisibleTo never see two copies. Your project compiles against that assembly but keeps no reference to it. If an older install added an <IncludeAssets> line without compile, remove it.

ReactiveUI 24 consumers can reference either ReactiveUI, for the API without System.Reactive, or ReactiveUI.Reactive, for the System.Reactive API. The generators detect the API you reference.

For .NET Framework 4.8 and older, add Polyfill or PolySharp and set LangVersion to 12.0 or later.

Overview

Roslyn and Visual Studio support

The package ships three analyzer bands. Your compiler picks the highest band at or below its own Roslyn version.

The roslyn4.8 band compiles against the Roslyn 4.8 API only, so it loads on every .NET 8 SDK band without the CS9057 error. See the Roslyn package version mappings.

Migration from ReactiveUI.Fody

1. Remove the ReactiveUI.Fody package, FodyWeavers.xml and FodyWeavers.xsd.
2. Add the ReactiveUI.SourceGenerators package.
3. Declare your classes and properties partial, put [Reactive] on them, and replace the ReactiveUI.Fody.Helpers using with ReactiveUI.SourceGenerators. [Reactive] also works on a backing field.
4. Replace Fody's [ObservableAsProperty] with ReactiveUI.Binding's.
5. Rebuild and check the generated code.

Reactive properties

using ReactiveUI.SourceGenerators;

public partial class MyReactiveClass : ReactiveObject
{
    [Reactive]
    private string _myProperty;
}

Options:

// Access modifier of the set accessor (not needed for a partial property: declare it on the property).
[Reactive(SetModifier = AccessModifier.Protected)]
private string _first;

// A virtual property.
[Reactive(Inheritance = InheritanceModifier.Virtual)]
private string _second;

// Also raise notifications for other properties.
[Reactive(nameof(Other1), nameof(Other2))]
private string _third;

// Pass an attribute to the generated property.
[Reactive]
[property: JsonIgnore]
private string _fourth;

From a partial property

Partial properties need C# 13 and Visual Studio 17.14 or later. Leave both accessors empty. virtual, override, required and a private or protected set accessor are written on the property itself. C# 14 also allows an initializer.

public partial class MyReactiveClass : ReactiveObject
{
    [Reactive]
    public partial string MyProperty { get; set; }
}

With other source generators

Roslyn does not order generators, and each one sees the original compilation. Code that one generator writes is invisible to the others in the same project. For example, the System.Text.Json generator does not see a [JsonPropertyName] that [Reactive] adds. To serialize [Reactive] properties with that generator, define the types in assembly A and the JsonSerializerContext in assembly B, which references A.

Reactive commands

public partial class MyReactiveClass
{
    [ReactiveCommand]
    private void Execute() { }                                          // ExecuteCommand

    [ReactiveCommand]
    private string Echo(string parameter) => parameter;                  // parameter and result

    [ReactiveCommand]
    private async Task<string> LoadAsync(string id) => await Task.FromResult(id); // LoadCommand: Async is dropped

    [ReactiveCommand]
    private IObservable<string> Watch(string id) => Observable.Return(id);

    [ReactiveCommand]
    private async Task Delay(CancellationToken token) => await Task.Delay(1000, token);
}

CanExecute

private IObservable<bool> _canSearch;

[ReactiveCommand(CanExecute = nameof(_canSearch))]
private void Search() { }

Schedulers and background work

RunInBackground runs a synchronous method on ReactiveUI's background scheduler. A task-returning method starts with Task.Run, so the code before its first await leaves the calling thread. The command parameter and CancellationToken are passed through. BackgroundScheduler chooses the scheduler a synchronous method runs on and implies RunInBackground.

OutputScheduler and BackgroundScheduler name a scheduler as you would write it in the class: a field, property or parameterless method of the class, or a static one elsewhere, such as RxSchedulers.MainThreadScheduler. A name that does not resolve to a scheduler is reported as RXUISG0021.

[ReactiveCommand(RunInBackground = true)]
private void Crunch() { }

[ReactiveCommand(BackgroundScheduler = nameof(_workScheduler))]
private void CrunchOnMine() { }

[ReactiveCommand(OutputScheduler = "RxSchedulers.MainThreadScheduler")]
private void ShowResult() { }

[ReactiveCommand(AccessModifier = PropertyAccessModifier.Internal)]
private void Hidden() { }

[ReactiveCommand]
[property: JsonIgnore]
private void Save() { }

A [ReactiveCommand] method with more than one parameter besides a CancellationToken (RXUISG0002), an async void method (RXUISG0008) and a scheduler name that does not resolve (RXUISG0021) are reported, because the generator skips them.

Views

[IViewFor] makes a partial control implement IViewFor<TViewModel>. It writes the ViewModel property and the interface members, and registers the view with ReactiveUI.Binding's view locator at compile time.

using ReactiveUI.SourceGenerators;

[IViewFor<LoginViewModel>]
public partial class LoginView : UserControl
{
}

// The view model by name, when its type is not in scope or is generic.
[IViewFor("Contracts.LoginViewModel")]
public partial class OtherView : UserControl
{
}

Derived lists and collections

public partial class MyReactiveClass : ReactiveObject
{
    // A ReadOnlyObservableCollection<string> property bound to a source list.
    [BindableDerivedList]
    private readonly ReadOnlyObservableCollection<string> _myList;

    // Change notifications on add, remove and replace.
    [ReactiveCollection]
    private ObservableCollection<string> _myCollection;
}

IReactiveObject for classes that cannot derive from ReactiveObject

[IReactiveObject]
public partial class MyReactiveClass
{
    [Reactive]
    private string _myProperty;
}

WinForms control hosts

using ReactiveUI.SourceGenerators.WinForms;

[RoutedControlHost("YourNameSpace.CustomControl")]
public partial class MyCustomRoutedControlHost;

[ViewModelControlHost("YourNameSpace.CustomControl")]
public partial class MyCustomViewModelControlHost;

Both resolve views through ReactiveUI's view locator, or through ReactiveUI.Binding's when your ReactiveUI is built on it. With ReactiveUI.Binding 8.4.0 or later they follow their own properties through Binding's ObservedProperty.

Working with ReactiveUI.Binding

ReactiveUI.Binding generates the code behind [ObservableAsProperty] and view registration. Use it for both.

A read-only property backed by an observable

Mark a partial property [ObservableAsProperty] (C# 13 or later). The generator writes the property body and a helper field named after it, which you assign with ToProperty:

using ReactiveUI;
using ReactiveUI.Binding;

public partial class MyReactiveClass : ReactiveObject
{
    public MyReactiveClass(IObservable<string> source) =>
        _myPropertyHelper = source.ToProperty(this, x => x.MyProperty, initialValue: "Default Value");

    [ObservableAsProperty]
    public partial string MyProperty { get; }
}

ReactiveUI.Binding needs a ReactiveUI release built on it. On ReactiveUI 24.3 and earlier, write the helper by hand:

private readonly ObservableAsPropertyHelper<string> _myPropertyHelper;

public string MyProperty => _myPropertyHelper.Value;

Generated code and intercepted calls

One generator cannot see another generator's output. The attribute generators therefore never write a call that ReactiveUI.Binding has to intercept (WhenAny*, Bind, OneWayBind, BindCommand). Generated code that follows a property uses Binding's ObservedProperty when it is available, and PropertyChanged otherwise.

Credits

Portions of this code base are based on and derived from

• PolySharp library. Thanks go to @Sergio0694
• Microsoft MVVM Community Toolkit

See our sponsors for the people and companies that support the project.
