TouchSocketPro.PlcBridges

项目概述

TouchSocketPro.PlcBridges 是一个高效、灵活的PLC数据桥接库，专为.NET开发者设计，用于简化与可编程逻辑控制器（PLC）的数据交互流程。该库提供了强大的数据读写管理能力，支持多种PLC协议和数据类型，使工业自动化开发更加便捷高效。

核心特性

🧩 驱动器管理系统

  • 地址范围管理：每个驱动器管理特定的PLC地址范围（起始地址+数量）
  • 地址重叠检测：自动检测并防止驱动器地址范围重叠
  • 分组执行：支持驱动器分组，相同分组的驱动器串行执行

⚡ 高效数据处理

  • 读写请求合并：智能合并相邻的读写请求，减少通信次数
  • 异步操作：全异步API设计，支持CancellationToken
  • 缓冲区管理：内置高效缓冲区，减少内存分配开销

📊 灵活的数据类型支持

  • 支持所有非托管数据类型（unmanaged）
  • 自定义字节序处理（EndianType）
  • 泛型驱动器和操作器实现

🔒 安全与可靠性

  • 只读驱动器支持
  • 完善的异常处理机制
  • 操作结果状态跟踪（Result）

单驱动读写

通过 PlcDriveOperator<TValue> 可以直接包装一个驱动器，构造后即可读写，支持现有的 IPlcOperator<TValue> 扩展和 PlcObject。

using var drive = new MemoryPlcDrive<short>(new PlcDriveOption
{
    Start = 100,
    Count = 1000
});
using var plcOperator = new PlcDriveOperator<short>(drive);

var writeResult = await plcOperator.WriteAsync(100, new short[] { 10, 20 });
var readResult = await plcOperator.ReadAsync(100, 2);
if (readResult.IsSuccess)
{
    ReadOnlyMemory<short> values = readResult.Value;
}

读写地址沿用驱动器的 Start/Count 范围。操作器内部独立串行调度，保留驱动器的请求合并、最大读写数量、只读限制等行为。多个操作器可分别包装地址相同的不同驱动器；各操作器之间不会按 Group 串行执行。一个驱动器只能由一个操作器或桥接服务调度。

释放操作器会停止调度并取消等待中的请求，驱动器由调用方释放。超时和调用方取消只结束请求等待，已经提交给驱动器的操作仍可能执行，与桥接服务的操作器行为一致。

性能优化

  • 请求合并：自动合并相邻地址的请求（通过MaxGap控制合并间隙）
  • 缓冲区复用：减少内存分配开销
  • 批量处理：单次执行处理多个读写请求

应用场景

  • 工业自动化控制系统
  • SCADA系统数据采集
  • PLC数据监控与分析
  • 自动化测试模拟环境
  • 工业物联网(IIoT)应用

文档说明

详细的说明文档请访问：https://touchsocket.net/

支持的目标框架

  • net462
  • net472
  • netstandard2.0
  • netstandard2.1
  • net6.0
  • net10.0
  • net8.0

贡献与反馈

如果你在使用过程中遇到问题或有任何建议，欢迎提交 issue 或参与项目贡献。
