UniFi Workflow Features

Provides a set of wrapper features Elsa Workflow 3 setup Server, including custom multitenancy, custom persistence, open telemetry, distributed locking, and more for UniFi Platform.

Installation

PM> NuGet\Install-Package UniFi.Workflow.Features -Version 1.0.1-rc3.5.0-1

Setup :

  • Create proj Asp.Net Core Web API
  • Add Configuration in appsettings.json
"WorkflowConfiguration": {
    "WorkflowPersistence": {
      "PersistenceORM": 2, // 0 = Memory, 1 = EntityFrameworkCore, 2 = PetaPoco
      "PersistenceProvider": 0, // // 0 = PostgresSQL, 1 = SqlServer, 2 = SqlLite
      "ConnectionStrings": {
        "PostgresSQL": "Server=127.0.0.1;Port=5432;Database=elsa;User Id=postgres;Password=password; Timeout=30; Pooling=False; No Reset On Close=True",
        "SqlServer": "Server=localhost,1433;Initial Catalog=Elsa;User=sa;Password=!Elsa2025@;Encrypt=false;PersistSecurityInfo=false",
        "MySql": "Server=localhost;Database=elsa;Uid=admin;Pwd=password;",
        "SqlLite": "Data Source=App_Data/elsa.sqlite.db;Cache=Shared;",
        "RabbitMq": "rabbitmq://api:admin@test.com",
        "Redis": "localhost:6379,abortConnect=false",
        "AzureServiceBus": ""
      }
    },
    "WorkflowIdentity": {
      "Tokens": {
        "SigningKey": "054d12a894250b1fac68adf67e56bc36db55141b1dc4b7e382fd4876ffffc4d0",
        "AccessTokenLifetime": "1:00:00:00",
        "RefreshTokenLifetime": "1:00:10:00"
      },
      "Roles": [
        {
          "Id": "admin",
          "Name": "Administrator",
          "Permissions": [
            "*"
          ],
          "TenantId": "demo"
        }
      ],
      "Users": [
        {
          "Id": "a2323f46-42db-4e15-af8b-94238717d817",
          "Name": "admin",
          "HashedPasswordSalt": "JEy9kBlhHCNsencitRHlGxmErmSgY+FVyMJulCH27Ds=",
          "HashedPassword": "TfKzh9RLix6FPcCNeHLkGrysFu3bYxqzGqduNdi8v1U=",
          "Roles": [
            "admin"
          ],
          "TenantId": "public"
        },
        {
          "Id": "b0cd0e506e713a9d",
          "Name": "demo",
          "Roles": [
            "admin"
          ],
          "HashedPassword": "8B0fFK/f/kk9GkVtzXfRJ2Y6cNyYVvLTfKouWcAcuPg=",
          "HashedPasswordSalt": "xlNWvEng8fRvo0McyJopbRJ2MJ9NIYV/4IY5dOZeiiw=",
          "TenantId": "demo"
        }
      ],
      "Applications": [
        {
          "Id": "e9cb5b6d6eb9d9d0",
          "Name": "postman",
          "Roles": [
            "admin"
          ],
          "ClientId": "pz6KkQn1SNfMJrVa",
          "ClientSecret": "0ip(9C0RdG\\Q4>60V&yh*2Wfwg3P$mf3",
          "HashedApiKey": "l6ezFYG3wqlvqzpv21P/F7rIU+qgcWubTDMDQ3JAESI=",
          "HashedApiKeySalt": "J3CBCKnV1TIbNEMXTNO3l2UKVPoFEWhkf7T9b427gzY=",
          "HashedClientSecret": "+GdqLrxOwAOzQUZupIWiOfM7OWQMWXoh8atdBUjbk/Y=",
          "HashedClientSecretSalt": "b5n8JHQB474NAIUD0N7kjznDuZz5GDmqY3xzvRMM024=",
          "TenantId": "public"
        }
      ]
    },
    "WorkflowManagement": {
      "UseReadOnlyMode": false,
      "LogPersistenceMode": 0 // 0 = Inherit, 1 = Include, 2 = Exclude
    },
    "WorkflowRuntime": {
      "RuntimeType": 0, // 0 = Default, 1 = Distributed, 2 = ProtoActor"
      "DistributedLockProvider": 0, // 0 = Noop, 1 = Postgres,  2 = Redis, 3 = File
      "DistributedLocking": {
        "LockAcquisitionTimeout": "00:00:10"
      },
      "WorkflowDispatcher": {
        "Channels": [
          {
            "Name": "Low"
          },
          {
            "Name": "Medium"
          },
          {
            "Name": "High"
          }
        ]
      }
    },
    "WorkflowMultitenancy": {
      "Multitenancy": {
        "Tenants": [
          {
            "Id": "public",
            "Name": "Tenant public",
            "TenantId": "public",
            "Configuration": {
              "Http": {
                "Prefix": "",
                "Host": ""
              },
              "ConnectionStrings": {
                "Sqlite": ""
              }
            }
          }
        ]
      }
    },
    "WorkflowOpenTelemetry": {
      "Enabled": false,
      "ServiceName": "elsa-workflows",
      "ServiceVersion": "3.5.0"
    },
    "WorkflowMassTransit": {
      "Enabled": false,
      "Broker": 1, // 0 = Memory, 1 =  RabbitMQ , 2 = Azure Service Bus
      "AppRole": 0, // 0 = Default, 1 = Api, 2 = Worker, 3 = Monitor
      "PrefetchCount": 50,
      "LockDurationMinutes": 5, //Azure Service Bus only
      "MaxDeliveryCount": 8, //Azure Service Bus only
      "ConcurrentMessageLimit": 32, // rabbitMQ only
      "Durable": true, // rabbitMQ only
      "AutoDelete": false // rabbitMQ only
    },
    "WorkflowScheduler": {
      "Enabled": false,
      "HangFire": true,
      "Quartz": true
    },
    "WorkflowActivity": {
      "Smtp": {
        "Host": "localhost",
        "Port": 2525,
        "DefaultSender": "noreply@test.com",
        "RequireCredentials": false,
        "UserName": "",
        "Password": ""
      },
      "http": {
        "BaseUrl": "https://localhost:5001",
        "BasePath": "/workflows",
        "ApiRoutePrefix": "elsa/api",
        "AvailableContentTypes": [
          "application/json",
          "application/xml",
          "text/plain",
          "text/html"
        ]
      },
      "UseEmail": true,
      "UseHttp": true,
      "UseLiquid": true,
      "UseJavaScript": true,
      "UseCSharp": true,
      "UsePython": true
    },
    "WorkflowRecurringTask": {
      "TriggerBookmarkQueueSecond": 300,
      "PurgeBookmarkQueueSecond": 300,
      "RestartInterruptedWorkflowsTaskSecond": 15,
      "RuntimeOptionsInactivityThresholdSecond": 15,
      "BookmarkQueuePurgeOptionsSecond": 10,
      "CachingOptionsDay": 1
   },
    "UseMultitenancy": true,
    "UseCompression": true,
    "UseCaching": true,
    "UseMemoryStore": true,
    "UseEfPoolingContext": false,
    "UseFluentStorage": false,
    "UseSwagger": false
  }
  • Add wrapper in Program.cs

Usage

var builder = WebApplication.CreateBuilder(args);
var services = builder.Services;

// Add service workflow
services.AddUniFiWorkflow(builder.Configuration, builder.Logging);

var app = builder.Build();

// Add app workflow
app.UseUniFiWorkflow();

Elsa Workflow 3

Elsa Workflows is a set of open-source .NET libraries designed to enhance .NET applications with workflow capabilities. Think of it as lego blocks for creating workflow engines in .NET See Elsa Workflow Documentation or Source for more details.

License

MIT
