Canvas.Views.Web 1.0.7-prerelease

Canvas and Open GL Stock and Financial Charts

The fastest charting web control targeting primarily Blazor, both Server Side and Web Assembly, or event ASP.NET MVC. This charting library was designed for Web, but it can also be used in Desktop apps via Web View. The main purpose of this library is to be used as a charting tool for real-time financial applications, e.g. backtesters for trading strategies. Here is the most comprehensive guide dedicated to charting in .NET that I have seen so far. Nevertheless, trying various options from that guide I wasn't able to find anything fast and flexible enough for my needs, so created my own.

• Usage samples can be found here
• Possible application of this library is here

Nuget

Install-Package Canvas.Views.Web -Version 1.0.7-prerelease

Drawing Methods

Currently available controls.

• Engine - base Canvas control exposing drawing context of various frameworks, like GDI or SkiaSharp
• CanvasEngine - a wrapper around SkiaSharp and Open GL

In order to add a different type of panel, e.g. GDI+ or Direct 2D, you need to implement IEngine interface.

Chart Types

At the moment, there are four built-in chart types.

• Line - line
• Bar - polygon
• Area - polygon
• Arrow - polygon
• Candle - OHLC box, a mix of a line and a rectangle polygon

If there is a need to create a new chart type, then you need to implement IGroupModel interface.

Pan and Zoom

The chart is completely data-centric, thus in order to scale the chart you need to change the data source. By default, the chart displays last 100 data points, as defined in IndexCount property.

MinIndex = Items.Count - IndexCount
MaxIndex = Items.Count

To pan the chart to the left, subtract arbitrary value from both MinIndex and MaxIndex.

MinIndex -= 1
MaxIndex -= 1

To pan the chart to the right, do the opposite.

MinIndex += 1
MaxIndex += 1

To zoom in, increase MinIndex and decrease MaxIndex to decrease number of visible points.

MinIndex += 1
MaxIndex -= 1

To zoom out, do the opposite.

MinIndex -= 1
MaxIndex += 1

Data source structure

The simplest format used by the library is a list of model with a single Point property.

// Blazor example

<CanvasWebView @ref="ViewControl"></CanvasWebView>

@code
{
  public CanvasWebView ViewControl { get; set; }

  protected override async Task OnAfterRenderAsync(bool setup)
  {
    var points = Enumerable.Range(1, 100).Select(i => new BarGroupModel
    {
      Index = i,
      Value = new Model { ["Point"] = new Random().Next(-5000, 5000) }
    } as IPointModel);

    ViewControl.Composer = new Composer
    {
      Name = name,
      Points = points.ToList(),
      Engine = new CanvasEngine(1000, 500)
    };

    ViewControl.Update();
  }
}

In case when charts have to be subchronizaed or overlapped within the same viewport, data source should have format of a list where each entry point has a time stamp and a set of Areas and Series that will be rendered in the relevant viewport.

[
  DateTime
  {
    Area A
    {
      Line Series => double,
      Candle Series => OHLC
    },
    Area B
    {
      Line Series => double,
      Line Series => double
    },
    Area C
    {
      Bar Series => double
    }
  },
  DateTime { ... },
  DateTime { ... },
  DateTime { ... }
]

• Area is a viewport, an actual chart, each viewport can show several types of series, e.g. a mix of candles and lines.
• Series is a single chart type to be displayed in the viewport, e.g. lines.
• Model is a data point of dynamic type, can accept different type of inputs, e.g. double or OHLC box.

At this moment, Painter supports only horizontal orientation, so the axis X is used as an index scale that picks data points from the source list and axis Y is a value scale that represents the actual value of each data point.
