Runic.Application.Testing 0.14.0

Runic.Application.Testing

Test a generated Runic Window contract and its routed Views without a browser or native window. RunicWindowTestHost<TViewModel> owns an in-memory transport, a real WindowContentSession, and the generated root Bridge attachment, so tests run the real ViewModels and generated .NET handlers. The caller owns the ViewModel and its dependency injection scope.

Testing

Build the application's own services, create a scope for the window, and create the host from it, with a test clock in place of the system clock:

var clock = new FakeTimeProvider();   // Microsoft.Extensions.Time.Testing
await using var services = new ServiceCollection()
    .AddSingleton<TimeProvider>(clock)
    .AddNotes()          // the application's registrations, including AddRunicViews()
    .BuildServiceProvider();
await using var scope = services.CreateAsyncScope();
using var host = RunicWindowTestHost.Create<ShellViewModel>(scope.ServiceProvider,
    new RunicWindowTestHostOptions { TimeProvider = clock });

RunicWindowTestHost.Create resolves what the Desktop and CS-WebUI windows resolve from the window's scope: the root ViewModel, its generated Bridge attachment (AddRunicViews() registers it), and, when registered, the IRunicViewLocator, the IRunicModelContext (for example from AddRunicReactiveModelContext() or AddRunicNavigation()) and the ILoggerFactory. A locator, context or logger factory set in the options is used instead. It names the missing registration when the ViewModel or its Bridge is not registered. The scope and its ViewModels stay yours; dispose the host before the scope. host.Services is the provider it resolved them from.

The services need two registrations: the ViewModel, as the application registers it (for example services.AddScoped<ShellViewModel>()), and the generated Bridge, which the application's generated AddRunicViews() adds. Register both with the application's own registration method when it has one, so the test runs the same composition. A ViewModel the test builds by hand needs no registration: pass it to Create, which still takes the Bridge, locator, model context and logger factory from the services (since 0.14):

await using var services = new ServiceCollection()
    .AddRunicViews()     // the application's generated Bridge registrations
    .BuildServiceProvider();
var shell = new ShellViewModel(new InMemoryNotes());
using var host = RunicWindowTestHost.Create(services, shell);

A Window opened on a real host has the same scope: window.Services (since 0.14) is the provider of the Window's dependency injection scope, which resolved its ViewModel, so a test can read the scoped services the ViewModel received.

The constructors take the ViewModel and the attachment directly, for a window that is not composed with dependency injection:

using Runic.Application.Views.Generated.Bridges;   // the generated ShellBridge

using var host = new RunicWindowTestHost<ShellViewModel>(shell,
    (transport, content, vm) => new ShellBridge(transport, vm, content: content),
    new RunicWindowTestHostOptions { ViewLocator = locator, TimeProvider = clock });

The generated bridges are internal, so this needs InternalsVisibleTo from the application to the test project. A test project that sees two applications' internals can find the same bridge name in both: name one by an extern alias of its reference, or create the host with RunicWindowTestHost.Create instead.

Then drive the Window by ViewModel member, as the generated TypeScript client does:

var sidebar = await host.Root.ViewAsync<SidebarViewModel>(vm => vm.Sidebar);
(await sidebar.ExecuteAsync(vm => vm.OpenNotesCommand)).ThrowIfFailed();
var document = await host.Root.ViewAsync<DocumentViewModel>(vm => vm.Main);
var editor = await document.ViewAsync<EditorViewModel>(vm => vm.CurrentPane);
(await editor.SetAsync(vm => vm.Title, "Groceries")).ThrowIfFailed();
(await editor.ExecuteAsync(vm => vm.TagCommand, new TagInput("shopping", Pinned: true))).ThrowIfFailed();

var save = await editor.StartAsync(vm => vm.SaveCommand);
Assert.True((await editor.SnapshotAsync()).IsExecuting(vm => vm.SaveCommand));
clock.Advance(TimeSpan.FromMilliseconds(250));   // storage waits on the injected clock
Assert.Equal(RunicOperationStatusKind.Succeeded, (await save.WaitAsync()).Kind);
Assert.Equal("Saved Groceries", (await editor.SnapshotAsync()).Read(vm => vm.SavedMessage));

Asynchronous and synchronous drivers

Every request has an asynchronous method that never blocks a thread (since 0.14): SnapshotAsync, SetAsync, SetJsonAsync, WriteAsync, ExecuteAsync, CanExecuteAsync, StartAsync, MountAsync, UnmountAsync, ViewAsync, ViewsAsync and TrackAsync on a driver, GetStatusAsync, CancelAsync and ReadStreamAsync on an operation, VerifyAsync on a tracker and RequestAsync on the transport. Concurrent requests on one connection share its hello.

The synchronous methods (Snapshot, Set, Write, Start, Mount, Request, ...) remain for short tests. They block the calling thread until the reply, while the window's own asynchronous work, such as a model turn or an awaited command, continues on thread-pool threads. A suite that runs many tests in parallel on the thread pool, as TUnit and xUnit do, can starve the pool this way: each blocked test holds a thread that the replies it waits for need, and the pool adds threads slowly. Use the asynchronous methods in such suites.

dotnet new runic-app --tests creates an application with a TUnit test project that does this for its Window; the CommunityToolkit Notes example is a larger xUnit project.

Skip the frontend build

A test project that references the application project builds the application, and by default that build installs and builds the frontend too. The host needs only the .NET assembly, so pass RunicApplicationFrontendBuildEnabled=false to the reference, as the template's test project does:

<ProjectReference Include="../MyApp/MyApp.csproj" AdditionalProperties="RunicApplicationFrontendBuildEnabled=false" />

The generated TypeScript clients are still written. In a solution that also builds the application itself, MSBuild then builds the application project twice, once with each setting; build the test project on its own, or leave the property out and let the frontend build's up-to-date check skip unchanged frontends.

Deterministic time and ids

RunicWindowTestHost.Create and both constructors give the window a FakeTimeProvider from Microsoft.Extensions.TimeProvider.Testing, which this package depends on, unless options supply another TimeProvider. Its time passes only through Advance or SetUtcNow, which fire due timers, CancellationTokenSource timeouts and Task.Delay(TimeSpan, TimeProvider) in order; a timer due now fires at once. The window uses it for interaction deadlines and DrainAsync timeouts; register the same instance in the application's services for its own time. host.Time returns it.

Work that waits on the clock does not finish by itself:

• ExecuteAsync of an awaited command that waits on the clock completes only after the test advances it. Start the call, advance the clock, then await the call:

  var save = editor.ExecuteAsync(vm => vm.SaveCommand);
  clock.Advance(TimeSpan.FromMilliseconds(250));
  (await save).ThrowIfFailed();


  Start returns at admission, so an operation can be inspected while it runs.

• Only code that takes the TimeProvider follows it. Task.Delay(TimeSpan), DateTime.UtcNow and ReactiveUI's schedulers (Throttle, Timer, RxApp.MainThreadScheduler) keep using real time. Give such code the clock, for example through a scheduler built on it, or test it with ReactiveUI's TestScheduler.

Content ids are 1, 2, ... in presentation order, so routes are content1, content2, ... and snapshots are stable. Set CreateId for another sequence. The drivers number presentation ids test-presentation1, ..., operation ids request1, ... and checked-write request ids write1, ... from one counter.

For real time, set TimeProvider = TimeProvider.System in the options.

File watchers

RunicPathWatchTester drives the RunicPathWatchers started with its Options (see Watching files): their debounce and polling run on its FakeTimeProvider, Time. Give the options to the ViewModel that starts the watcher:

using var watching = new RunicPathWatchTester();
using var overview = new OverviewViewModel(context, watching.Options);

File.WriteAllText(Path.Combine(checkout, "flake.lock"), lockText);
var change = await watching.NextChangeAsync();     // after the callback ran in the model context

// A path the test cannot change: report it as if the platform had.
await watching.TriggerAsync("/run/current-system");

• NextChangeAsync returns the next change not returned yet, once its callback has run. While none is reported, it advances Time one debounce interval at a time, so events that arrive from a real file system are delivered. It throws TimeoutException after 10 seconds of real time. Each of the three waits also takes a CancellationToken.
• TriggerAsync(path) marks the targets with that path changed in every active watcher, whether or not they changed, and returns NextChangeAsync. It throws InvalidOperationException when no active watcher has such a target.
• DrainAsync advances Time for 300 ms of real time and returns what was reported meanwhile, to assert that a burst produced one change or nothing more.
• ActiveWatchers counts the watchers that are started and not disposed, to check that a ViewModel stops its watcher.
• Dispose stops the watchers that are still active and detaches the tester from its options, so a watcher a test did not dispose does not outlive it. Each change's Entries names the paths that changed (see Watching files).

Drivers

host.Root drives the root ViewModel. View<T>(vm => vm.Content) and Views<T>(vm => vm.Items) follow the content references in the current snapshot and check that they present T; host.View<T>(reference) drives a reference you already have. A RunicViewDriver<T> has:

• Snapshot(): a RunicViewState<T> with Read(vm => vm.Title) for scalars (a string, Boolean, Int32, Int64, double, decimal, GUID or enum), Get for the raw JSON of other values, Reference, References, Keys of a [RunicCollection], CanExecute, IsExecuting and FieldVersion. Read of a record, DTO or collection throws NotSupportedException naming the property; use Get(vm => vm.Item).GetProperty("wireField") instead.
• Set(vm => vm.Title, value), encoded as the generated client encodes it: an int, bool or non-nullable string as is, and other scalars as wire JSON (Int64 and decimal as strings, enums by wire name, null for nullable values). Since 0.14 a DTO, list or union is encoded as for a typed command input (below); SetJson takes wire JSON.
• ExecuteAsync(vm => vm.SaveCommand, argumentJson), which waits for an asynchronous command, and CanExecute(command, argumentJson) for commands with an argument. ExecuteAsync(command, argument), CanExecuteAsync(command, argument) and StartAsync(command, argument) take the input as a .NET value instead (since 0.14) and encode it as the generated client does: scalars as Set encodes them, a record or class as an object of its properties by wire name (camelCase, or its [RunicAlias] or [JsonPropertyName], without [RunicIgnore] and [JsonIgnore] members), a [RunicUnion] case with its $case, lists as arrays, string-keyed dictionaries as objects and a [RunicCodec] type by its codec. A string input binds to the wire JSON overload unless you name the type: ExecuteAsync<string>(vm => vm.SearchCommand, "milk"); a string that is not JSON throws ArgumentException that says so. A command whose [RunicCommandKey] resolver is asynchronous answers only after the resolver, so use CanExecuteAsync and StartAsync for it (since 0.11); CanExecute and Start throw InvalidOperationException for such a command instead of blocking the test thread, which may own the fake clock or the model turn the resolver waits for. A reply has Succeeded, ErrorKind, ErrorReason (since 0.11: unavailable, invalid-input or unresolved-key for a rejected call), ErrorMessage, Revision, Released and Superseded. A Views protocol 4 reply names the revision that includes the call's effects instead of carrying state, so the driver reads State with a snapshot request after the reply, when the reply has a revision. Released is true when the call released its own route, as a command that navigates away does, and Superseded when a set was not applied because a later edit of the member was admitted first. ThrowIfFailed() throws for a failed call, as NavigationResult does. A command's declared failure ([RunicFailure]) replies with ErrorKind domain-failed and the encoded failure as Failure, such as {"$case":"titleRequired"}. A call of a released View or a closed window replies released.
• Start(command, argumentJson, requestId) for a recoverable operation. Its Admission is a RunicOperationAdmissionKind (Accepted, Duplicate, ...). It has GetStatus(), WaitAsync() and Cancel(), which returns a RunicOperationCancelKind (CancellationRequested, NotRunning, ...). A status has a RunicOperationStatusKind Kind (Running, Succeeded, Failed, DomainFailed, Cancelled, Expired, or Unknown for a request the window does not know), Result, ErrorMessage and, for a DomainFailed operation, Failure. ReadStream(cursor) reads a streamed operation's retained items after cursor as the generated client's stream(cursor) does: a RunicOperationStreamPage with the status Kind, the encoded Items, the Cursor of the next page, Completed, and DeliveryKind and DeliveryMessage when items were dropped (stream-overflow, ...). The delivery kinds, like BridgeOperationDeliveryFailureKind in .NET and TypeScript, are open: a minor release may add one.
• Write(vm => vm.Title, value, expectedVersion) for a checked write. It uses the current value and version as the baseline unless expectedVersion is given, so a stale version tests the Conflict receipt. A receipt has a RunicFieldWriteReceiptKind Kind, ErrorMessage, Value, Version and State, read like a reply's.
• Mount(presentation) sends open for a presentation of the route, as a page that shows the View does, and returns the presentation id (test-presentation{n} when omitted); Unmount(presentation) sends close. Both take optional client and connection keys and throw InvalidOperationException naming the route's reply unless it accepted the request, for example when another client's keys close it (ignored) or the route was released.
• TakePublications() and NextPublicationAsync() return this route's pushes in order, each a RunicViewPublication whose Kind is State (with State and Fields), Frame (with BaseRevision, the member Sets (RunicMemberSet), the keyed collection Changes (RunicCollectionChange) and the text Texts (RunicTextChange)), or Failure. Revision names the revision of each.

Navigation

A NavigationRegion<TContent> slot is an ordinary content slot, so the same host and drivers apply. Create the navigator with the window's model context and pass that context as RunicWindowTestHostOptions.ModelContext; a generated Bridge rejects a session whose context is not the navigator's. A NavigationSelection slot is a nullable number: read the selected index with Snapshot().Get(vm => vm.Tabs), which is JSON null for an empty selection.

using Runic.Navigation; // RunicNavigator and RunicModelContext
await using var context = new RunicModelContext();
await using var navigator = new RunicNavigator(new() { ModelContext = context, TimeProvider = clock });
var shell = new ShellViewModel(navigator);
using var host = new RunicWindowTestHost<ShellViewModel>(shell, attach,
    new RunicWindowTestHostOptions { ModelContext = context, TimeProvider = clock });

// A scripted guard: the test page's CanDepartAsync returns decision.Task, which
// holds the transition in Guarding until the test decides.
var decision = new TaskCompletionSource<bool>();
editor.Departure = decision.Task;
var back = shell.Main.BackAsync();
decision.SetResult(true);
await back;
await navigator.WhenIdleAsync();
var home = host.Root.View<HomeViewModel>(vm => vm.Main); // the resumed entry

• RunicNavigator.WhenIdleAsync() waits until no transition or retirement is running.
• navigator.UnretiredEntryCount counts entries that have not finished retiring (zero after DisposeAsync), and host.Content.RetainedContentModelCount(), an extension on the window's WindowContentSession, counts the content models whose model-context leases the window holds.
• Pass a FakeTimeProvider as RunicNavigatorOptions.TimeProvider to drive the close timeout and the overrun warning (event 1067) without waiting.

With AddRunicNavigation(), create the window scope with CreateAsyncScope(), because the navigator is only IAsyncDisposable. RunicWindowTestHost.Create gives the window the scope's IRunicModelContext, which the navigator shares:

await using var scope = services.CreateAsyncScope();
using var host = RunicWindowTestHost.Create<ShellViewModel>(scope.ServiceProvider,
    new RunicWindowTestHostOptions { TimeProvider = clock });

A unit test of one page that takes its NavigationEntryContext, such as a dialog that completes its request, needs no window. RunicTestNavigationEntry (since 0.11) pushes the page on a test navigator with its own RunicModelContext, as a region does in the application, and exposes the context, the request's completion and the transitions that change the entry's state:

await using var dialog = await RunicTestNavigationEntry.CreateAsync(
    entry => new ConfirmNavigationViewModel(entry, "Discard the unsaved edits?"));

await dialog.Content.ConfirmCommand.ExecuteAsync(null);

await Assert.That(await dialog.Completion).IsEqualTo(new NavigationCompletion<object?>.Completed(true));
await Assert.That(dialog.Context.State).IsEqualTo(NavigationEntryState.Retired);

• The navigator constructs the content through create, so its navigation hooks, guards and INavigationAware calls run as in the application, and it owns and disposes the content when the entry retires. Pass services for the entry's Services.
• The entry is pushed for an object result: Completion reports CompleteAsync with any value, and Dismissed when the entry leaves otherwise.
• RetainAsync pushes another entry over it, ActivateAsync goes back to it, and RetireAsync clears the region. Each returns the NavigationResult, so a guard's veto is visible. Navigator and Region are there for anything else; disposing the object closes the navigator.

Write navigation tests so they are deterministic:

• Hold a transition in a phase with a TaskCompletionSource that a guard, InitializeAsync or ResumeAsync awaits. Signal a second one from the hook when the test must know that the hook started. Then the test decides when the hook continues, instead of racing it.
• Don't await a request whose guard waits for the test. Start it, wait for the observable effect, answer, then await it. For example, start the Back, wait until the dialog region's Current is set, execute the dialog's command through its driver, and then await the Back. A command driver's Start returns at admission, which suits a command that navigates.
• Wait for region changes with PropertyChanged, not with delays. Every change is raised inside a model turn.
• await navigator.WhenIdleAsync() before you assert on retirement: departing entries retire after the commit turn, and owned content is disposed then.
• Assert lifetimes through the counters. navigator.UnretiredEntryCount falls as entries retire, and is zero after DisposeAsync. RetainedContentModelCount() falls when owned content's leases are released. Assert Retired states and disposal counts of your own test content too.
• Make overruns and timeouts happen by advancing the FakeTimeProvider: 5 seconds for event 1067, and CloseTimeout for disposal.
• To provoke a race, drive overlapping requests from a seeded Random, and assert invariants that don't depend on timing. For example, every request ends, an entry retires at most once, and nothing is left unretired after DisposeAsync.

The Notes tests cover a guard that asks in a dialog region with PushForResult, resuming a retained entry, retirement of a parent's child regions, racing navigation and closing the window while the dialog asks; ConfirmNavigationTests tests the dialog page on its own with RunicTestNavigationEntry.

Interactions

A test answers a ReactiveUI Interaction, such as the question of a ReactiveLeaveConfirmation.WithInteraction guard, with a .NET handler on the ViewModel. ReactiveUI asks the latest handler first, so a handler the test registers answers before a fallback registered in the ViewModel's constructor; dispose it to restore the fallback. From the ReactiveUI WPF navigation tests:

var answers = new Queue<bool>([false, true]);
var prompts = new List<string>();
using var handler = detail.ConfirmDiscard.RegisterHandler(context =>
{
    prompts.Add(context.Input);
    context.SetOutput(answers.Dequeue());
});

This is the supported test path for a question that a web View answers in the browser. The host does not run the generated TypeScript client, and a driver's Mount() opens a presentation without registering any interaction handler, so the question never waits for a browser: it goes to the .NET handlers. The test still covers everything the ViewModel decides: the guard, the prompt's input, and what each answer keeps or discards. With no handler that answers, the departure fails closed with ReactiveUI's UnhandledInteractionException, as in the application.

The browser's side is tested with the frontend: the generated typed mock's interactions.<name>.request(input) resolves with the answer of the handler the View registered with interactions.<name>.handle(...); see the Testing guide. Which View is asked for which departure, and the fallback when none is mounted, are covered by the SDK's own tests and described in Leave confirmation in a web View.

CommunityToolkit.Mvvm has no interaction type: a Toolkit guard asks in a dialog region, and a test answers it by executing the dialog's command through its driver, as in Navigation.

Collections and frames

Track() follows a route from a snapshot through its pushes, as the generated client does: newer full states replace the state, frames must continue the tracked revision (BaseRevision), and their keyed collection changes must name the row keys they change; failure notices are collected. A frame the client could not apply throws, naming the problem: a lost or reordered frame, more than 4,096 changes, a set beside another change of the same member, a member the View does not have, a missing or unexpected checked-field version, a text change whose length does not match, an index outside the rows, a row key that does not match, an item count that does not match the keys, or an empty or duplicate key. FullStates counts the full states and Deltas the frames it applied.

var tracker = host.Root.View<HomeViewModel>(vm => vm.Main).Track();
library.Record("Groceries", "Milk, eggs");
var state = await tracker.WaitUntilAsync(state => state.Keys(vm => vm.RecentNotes)[0] == "Groceries");
Assert.Equal(0, tracker.FullStates);                       // only keyed changes were sent
Assert.Contains(tracker.Changes, change => change.Kind == RunicCollectionChangeKind.Move);
tracker.Verify();                                          // the frames match a fresh snapshot

Publications are delivered off the calling thread, so waits use real time, RunicWindowTestHostOptions.PublicationTimeout (five seconds by default). A route's frames go to its tracker or to TakePublications, not both.

Lower level

host.Transport is the InMemoryBridgeTransport, the window's IBridgeConnectionTransport. Request(json) and RequestAsync(json) send a Views protocol 4 request on a connection (hello first), CloseConnection closes it, and Messages/TakeMessages() list the pushes the window sent, such as host.Transport.Request($$"""{"kind":"snapshot","route":"{{host.RootRoute}}"}""") for the raw reply that host.Root.Snapshot() parses. Each RunicBridgeMessage has the push's Json, the ConnectionKey of a push to one connection, or null for a broadcast, and, read from the JSON, its Kind (state, frame, failure, operation, ...) and Route (since 0.14), so host.Transport.TakeMessages().Where(message => message.Route == editor.Route) selects one route's pushes. DefaultConnectionKey (connection-1) and DefaultClientKey (client-1) are the keys of requests that name none. The verb is Take, as on the drivers, because the pushes are removed; Drain names DrainAsync, which waits for accepted work. A driver's Mount and Unmount (open and close) with client and connection keys and Transport.CloseConnection test View lifetimes and client disconnects. Await host.DrainAsync(timeout) before disposing a host that has accepted background operations. It stops admission, as a closing window does. With a fake clock its timeout passes only when the clock advances, and its token stops only the wait.

The host does not instantiate the application's native Window wrapper or run the generated TypeScript client or a rendering framework. Test the frontend with the generated typed mocks of @runic-artifex/views/mock; see its Testing guide. To drive the whole application in a browser, use RunicServeOnlyApplication (below); to run script in the embedded Runic Desktop View from an in-process test, use DesktopBridgeWindow<TViewModel>.Surface.ExecuteJavaScriptAsync. See the Runic.Application.Views.Desktop automation section.

Custom window hosts

Runic Desktop, CS-WebUI, WPF and this package carry the Views protocol over an IBridgeTransport from Runic.Application.Views. A host of your own, such as one that serves pages over its own WebSocket, implements the same interface; the protocol it carries is in the Views protocol. The window calls Serve once with its IBridgeRequestHandler and sends every push through BroadcastAsync. A transport that can push to one connection outside a request also implements IBridgeConnectionTransport.SendAsync; without it, the window keeps each connection's targeted pushes in a mailbox (1,024 pushes and 4 MiB at most), and the page's host script drains it with receive requests, as CS-WebUI's does. The transport:

• passes each request to HandleAsync as a BridgeRequest with the message and the client and connection keys it authenticated, never keys read from the message, in the order the connection received them, without waiting for earlier replies: a receive or an awaited command stays open for long;
• sends the replies and pushes of one connection in the order the window sent them, and completes BroadcastAsync and SendAsync once the push is queued on every connection ahead of later sends;
• copies a push that it keeps after BroadcastAsync or SendAsync completed: the message is valid only until then, because the window returns its pooled memory and reuses it for later pushes;
• answers a request while no handler is served with the released reply, and reports each closed connection once with ConnectionClosed. A reconnect is a new connection with a new connection key.

using System.Collections.Concurrent;
using Runic.Application.Views;

// PageSocket is the host's own connection: it writes replies and pushes in call order, and its
// Closing token is cancelled when the connection closes.
public sealed class SocketBridgeTransport : IBridgeConnectionTransport
{
    private static readonly byte[] Released =
        """{"ok":false,"error":{"kind":"released","message":"This View was released."}}"""u8.ToArray();
    private readonly ConcurrentDictionary<string, PageSocket> _pages = new();
    private IBridgeRequestHandler? _handler;

    public IDisposable Serve(IBridgeRequestHandler handler)
    {
        if (Interlocked.CompareExchange(ref _handler, handler, null) is not null)
            throw new InvalidOperationException("The transport already serves a handler.");
        return new Lease(() => Interlocked.CompareExchange(ref _handler, null, handler));
    }

    public async ValueTask BroadcastAsync(ReadOnlyMemory<byte> message, CancellationToken cancellationToken = default)
    {
        foreach (var page in _pages.Values) await page.PushAsync(message, cancellationToken);
    }

    public async ValueTask<bool> SendAsync(string connectionKey, ReadOnlyMemory<byte> message,
        CancellationToken cancellationToken = default)
    {
        if (!_pages.TryGetValue(connectionKey, out var page)) return false;
        await page.PushAsync(message, cancellationToken);
        return true;
    }

    public void Opened(PageSocket page) => _pages[page.ConnectionKey] = page;

    // The socket's read loop calls this for each request, in arrival order, with a buffer of its own.
    public void Received(PageSocket page, long requestId, ReadOnlyMemory<byte> message)
    {
        if (Volatile.Read(ref _handler) is not { } handler) { _ = page.ReplyAsync(requestId, Released); return; }
        _ = ReplyAsync(page, requestId, handler.HandleAsync(
            new BridgeRequest(message, page.ClientKey, page.ConnectionKey), page.Closing));
    }

    public void Closed(PageSocket page)
    {
        if (_pages.TryRemove(page.ConnectionKey, out _)) Volatile.Read(ref _handler)?.ConnectionClosed(page.ConnectionKey);
    }

    private static async Task ReplyAsync(PageSocket page, long requestId, ValueTask<ReadOnlyMemory<byte>> reply) =>
        await page.ReplyAsync(requestId, await reply);

    private sealed class Lease(Action dispose) : IDisposable
    {
        public void Dispose() => dispose();
    }
}

The page's script installs __runicBridge with request, onMessage and onConnectionChange, as the host bridge describes, and the window attaches its generated Bridge to the transport with new WindowContentSession(transport, options) and the factory that AddRunicViews() registers, as the constructors above take it.

Test the window side over InMemoryBridgeTransport, which implements the same contract: RunicWindowTestHost runs the window on it, and a host's own composition can take new InMemoryBridgeTransport() in place of its transport and drive it with Request, CloseConnection and TakeMessages. Test the transport itself with a stub IBridgeRequestHandler that records the requests, keys and ConnectionClosed calls it receives and replies in an order the test chooses, so a test can check that replies and pushes keep their order and that a slow reply does not hold up the next request.

Compatibility

• The enums say in their documentation whether they are closed or open. RunicCollectionChangeKind and RunicPublicationKind are closed. The operation, admission, cancellation and receipt kinds are open: a minor release may add a value, so a switch over one needs a default arm. ErrorKind and ErrorReason are strings because BridgeError kinds and reasons are open sets that Runic.Application.Views owns.
• The package has no test-framework types. Failures throw InvalidOperationException or TimeoutException, so it works with TUnit, xUnit, NUnit and MSTest alike, as Runic.CommandLine.Testing and ASP.NET Core's WebApplicationFactory do.
• It uses internals of Runic.Application.Views, so it references that package at exactly its own version. Keep both at the same version.
• The constructors' attach parameter, Func<IBridgeTransport, WindowContentSession, TViewModel, IDisposable>, is the factory the generated AddRunicViews() registers. It changes only together with the generated code.
• RetainedContentModelCount() counts every content model whose model-context lease the window holds, not only navigation entries. It is a test-only view of window internals, which WindowContentSession does not expose.

The whole application in a browser

RunicWindowTestHost runs the ViewModels without a page. To test the real page against the real ViewModels, start the built application in serve-only mode with RunicServeOnlyApplication and point a browser at its URL. It works with an application on Runic Desktop or CS-WebUI and with any browser driver. With Playwright for .NET and TUnit:

[Test]
public async Task IncrementsTheCount()
{
    // The application, built next to the tests, for example through a ProjectReference.
    var start = RunicServeOnlyApplication.CreateStartInfo(
        Path.Combine(AppContext.BaseDirectory, "MyApp.dll"));
    await using var app = await RunicServeOnlyApplication.StartAsync(start);

    using var playwright = await Playwright.CreateAsync();
    await using var browser = await playwright.Chromium.LaunchAsync();
    var page = await browser.NewPageAsync();
    await page.GotoAsync(app.Url.ToString());
    await page.GetByRole(AriaRole.Button, new() { Name = "Increment" }).ClickAsync();
    await Assertions.Expect(page.GetByTestId("count")).ToHaveTextAsync("1");

    var children = app.GetDescendantProcesses();   // while the application runs
    await browser.CloseAsync();
    await Assert.That(await app.StopAsync()).IsEqualTo(0);
    await Assert.That(children.All(child => child.HasExited())).IsTrue();
}

StartAsync sets RUNIC_APPLICATION_SERVE_ONLY=1, removes DISPLAY and WAYLAND_DISPLAY, so no window can open, and waits up to 30 seconds (its timeout) for the first RUNIC_APPLICATION_URL= line. It reports an application that exits or stays silent with its standard output and standard error, which StandardOutput and StandardError also return. Add arguments or environment variables to the ProcessStartInfo before starting it; CreateStartInfo runs a .dll with dotnet. StartAsync uses the file name, arguments, working directory and environment and leaves the ProcessStartInfo unchanged, so it can start the application again.

StopAsync writes a line to standard input, which ends serving on every platform, and returns the exit code. When the application has not exited within its timeout (30 seconds), its process tree is killed and TimeoutException is thrown. The line is written once: another StopAsync, for example after a cancelled one, waits for the same exit with its own timeout, and after a kill it throws InvalidOperationException. Disposing stops the application the same way but kills a hanging one without an exception, so call StopAsync when a test should fail on a shutdown that hangs. To check that the application ends the processes it started, such as a long-running tool it cancels on shutdown, list them with GetDescendantProcesses while it runs and call HasExited() on each after StopAsync. A process whose parent has exited is no longer listed as a descendant. Each RunicDescendantProcess is a snapshot of the process id and start time that holds no process handle, so there is nothing to dispose. HasExited() looks the process up again and also reports a process whose id the system has since given to another process as exited.

A test process that exits without disposing the application still ends it on a best-effort basis: on Windows the application runs in a job object that ends with the test process, even when the test process is killed, and elsewhere the application is killed when the test process exits normally. A test process that is killed itself on Linux or macOS, for example with SIGKILL or by a crash, can leave the application running.

The page connects to the real Bridge, and the serve-only surface admits one browser. A test in TypeScript can follow the same protocol, described in the Runic.Application.Views.Desktop automation section: start the application with RUNIC_APPLICATION_SERVE_ONLY=1, read the RUNIC_APPLICATION_URL= line, and write a line to its standard input to stop it.
