VeloxDev.Core 10.0.1

VeloxDev

A node-editor and workflow-engine framework for .NET.

One model, seven GUIs. Build the editor above with WPF, Avalonia, WinUI, MAUI, WinForms, Blazor/Razor, or Jalium — the same graph model, commands and execution engine behind all of them. The same model also runs headless through VeloxDev.Core, so the interactive and non-interactive paths are one implementation.

Documentation · NuGet · Examples · MIT License

What this repository is

A workflow is a tree of nodes. Nodes own slots, slots are wired into links, and a slot declares a channel — how many connections it accepts in each direction — so the model itself knows which wiring is legal.

VeloxDev is built around that model, for the two ways it gets used:

• Interactive — a person edits a node editor: drags nodes, wires ports, pans and zooms, undoes structural changes.
• Non-interactive — a program, a service, or an AI agent builds the graph, compiles it, and runs it headlessly.

These are not two implementations. They use the same model, the same commands, the same connection validation and the same undo stack. A graph edited on a canvas runs in a console; a graph built by code or an Agent opens on the canvas and can be edited there.

The four layers

The source generator (VeloxDev.Core.Generator) is what makes the model pleasant to write: it turns [WorkflowBuilder.*], [VeloxProperty] and [VeloxCommand] into INotifyPropertyChanged, commands, helper lifecycle and serializer code. It ships inside the packages as an analyzer.

What it solves

Packages

dotnet add package VeloxDev.Core              # the graph model + engine, no UI
dotnet add package VeloxDev.WPF               # one adapter (brings Core)
dotnet add package VeloxDev.Core.Extension    # optional — the AI surface

VeloxDev.Core itself targets netstandard2.0, netframework4.6.1, net5.0, netcoreapp3.0 and net8.0, and declares IsAotCompatible on net8.0. Trimming and AOT remain per-platform realities: the adapters enable the analyzers, but the GUI framework itself may not support them.

Generate the view suite

Each adapter ships a template pack with the same seven items.

dotnet new install VeloxDev.WPF.Templates

dotnet new wpf-v-tree      -n WorkflowView     -ns MyApp.Views
dotnet new wpf-v-node      -n NodeView         -ns MyApp.Views
dotnet new wpf-v-slot      -n SlotView         -ns MyApp.Views
dotnet new wpf-v-link      -n LinkView         -ns MyApp.Views
dotnet new wpf-v-selector  -n TemplateSelector -ns MyApp.Views
dotnet new wpf-v-decorator -n GridDecorator    -ns MyApp.Views
dotnet new wpf-v-minimap   -n MinimapOverlay   -ns MyApp.Views

Other adapters use their own prefix: ava-v-*, winui-v-*, maui-v-*, winforms-v-*, razor-v-*, jalium-v-*.

Workflow in code

The snippets below walk one three-node chain: ticker → bias → printer.

A node is a partial class

// The generator supplies INotifyPropertyChanged, the commands and the Helper lifecycle.
[WorkflowBuilder.Node<BiasNodeHelper>]
public partial class BiasNodeViewModel
{
    public BiasNodeViewModel() => InitializeWorkflow();

    [VeloxProperty] public partial SlotViewModel Input { get; set; }
    [VeloxProperty] public partial SlotViewModel Output { get; set; }
    [VeloxProperty] private string title = "Bias";
}

public sealed class BiasNodeHelper : NodeHelper<BiasNodeViewModel>
{
    // What this node computes. The return value is passed to the next node in the chain.
    public override Task<object?> ReceiveAsync(ITaskContext context, CancellationToken ct)
        => Task.FromResult<object?>($"{context.Data}->bias");
}

Slot types are declared the same way, with [WorkflowBuilder.Slot<...>]. A slot's Channel decides its capacity:

output.SetChannelCommand.Execute(SlotChannel.MultipleTargets); // fan out from this port
input.SetChannelCommand.Execute(SlotChannel.OneSource);        // one upstream connection only

Edit through the same commands the canvas uses

tree.CreateNodeCommand.Execute(bias);
tree.SendConnectionCommand.Execute(ticker.Output);   // start from the sender…
tree.ReceiveConnectionCommand.Execute(bias.Input);   // …complete on the receiver
tree.UndoCommand.Execute(null);                      // the connection is one undoable step

Connection legality is a host rule, not a hard-coded policy:

public sealed class GraphHelper : TreeHelper<GraphViewModel>
{
    public override bool ValidateConnection(
        IWorkflowSlotViewModel sender, IWorkflowSlotViewModel receiver)
        => receiver.Parent is not SinkNodeViewModel;   // your rule
}

During a drag, the same rules produce a preview for the candidate port, with a reason when it is invalid. A host can narrow a valid candidate further, but cannot turn a framework rejection into a valid one.

Compile once, run deterministically

var compiler = new CompilerViewModel();
var graph = (await compiler.CompileAsync(ticker, CompileRole.Root)).Single();

var session = new RuntimeContext { Data = "seed" };
await new RuntimeEngine().RunAsync(graph, session, CancellationToken.None);

Console.WriteLine(session.Data);   // seed -> tick -> bias -> print

CompileRole.Root walks downstream from a start node. CompileRole.Terminal does the opposite — it compiles only the ancestor cone needed for one node's result, and needs no start node:

var cone = (await compiler.CompileAsync(printer, CompileRole.Terminal)).Single();

var probe = new RuntimeContext { Target = printer };
await new RuntimeEngine().RunAsync(cone, probe, ct);

Console.WriteLine(probe.TargetReached ? probe.Data : "target not reached");

The execution model is deliberately explicit:

• Branches are real. A node implementing ICompileTimeRouter compiles to a branch; static keys are pruned at compile time, dynamic keys are resolved at runtime. If a router selects a sibling branch, the target is reported as not reached — never fabricated.
• Fan-out is concurrent, joins are keyed. A route key with several targets compiles to a parallel segment; a join receives an IGroupData keyed by the upstream node, so "wait for all inputs" works regardless of interleaving.
• Loops are redirects, not cycles. IRedirectable returns an earlier compile order and the engine re-runs the graph from there, up to 50 redirects per run.
• Run controls are optional session objects. ExecutionGate, Observer, RetryPolicy, ErrorSink, Compensation and CheckpointStore are attached to RuntimeContext; none of them changes a run when absent.
• Outcome and position are separate. TargetReached says the target was driven; Outcome says whether the run completed, was cancelled or failed.

Input is routed; appearance is yours

Adapters translate native pointer and key input once. Core routes it to the hit component, then along its ancestors, and delivers Exited before the next Entered:

if (link?.GetHelper() is IInputEvents events)
{
    events.Input.PointerEntered += (_, _) => IsHighlighted = true;
    events.Input.PointerExited  += (_, _) => IsHighlighted = false;
}

There is no ILinkHighlight in Core, and that is intentional. The library supplies events, hit testing against the curve the view actually painted, and a per-action handle. The host decides what a hover looks like; a handler can set PreventDefault to veto one framework action, such as Delete, without disabling it globally.

Ports that change shape

[VeloxProperty]
[SlotSelectors(typeof(PythonPortProvider))]
public partial SlotEnumerator<SlotViewModel> Inputs { get; set; }

Changing the selector rebuilds the port set. Links are restored by name when the provider stays the same, and by position when the selector type changes. The same operation is available to the Agent as SetEnumSlotCollection.

AI control (optional)

The Workflow Agent turns a tree into a tool surface for any IChatClient. Every mutation goes through the same component command the GUI dispatches, so the Agent and the canvas share one edit path and one undo stack.

var scope = tree.AsAgentScope()
    .WithAutoDiscovery()
    .WithMaxToolCalls(200)
    .WithAllowNodeExecution(true)                              // node execution is off by default
    .WithSynchronizationContext(SynchronizationContext.Current);

var agent = chatClient.AsAIAgent(
    scope.CreateContextProviders(),
    instructions: scope.ProvideProgressiveContextPrompt());

What keeps the surface safe under a real session:

• Node execution is opt-in. Until the host calls WithAllowNodeExecution(true), execution tools are absent.
• Budgets are enforced. WithMaxToolCalls, plus separate read and write caps, bound a session.
• Interaction is explicit. Selection and confirmation tools appear only when the host wires a handler.
• Plans can be read before they run. CompileWorkflow / CompileNodeResult expose the plan. RunCompiledWorkflow waits for the end; StartCompiledWorkflow returns a handle that can be paused, resumed, polled or stopped.
• MCP, skills and sub-agents are separate subsystems. Each can also be used on its own; an MCP server joins the tool set on the next turn without rebuilding the agent.

Transition in code

The same source also ships the rendering layer the editor uses for polish. A transition is a chain you build, then execute:

var fade = Transition<Rectangle>.Create()
    .Property(r => r.Opacity, 0d)
    .Effect(new TransitionEffect { Duration = TimeSpan.FromSeconds(0.4), Ease = Eases.Cubic.Out });

fade.Execute(rect);

Several transitions can share one timeline: pausing, seeking or re-rating it moves all of them, while each keeps its own progress. The adapters contribute only a frame pacer where the platform has one (Razor deliberately has none); easing, keyframes, sampling and scheduling are Core code shared by all seven.

The other layers

All of these live in VeloxDev.Core and need no canvas.

Repository map

License

Released under the MIT License. © 2025 Axvser
